Product Description
| Product Brand | ChuanHangDisplay | Product Model | CH26439 |
| Resolution | screen size | 2.13" | |
| Outline Dimension(L*W*H) | 84.0x41.0x5.2mm | Visible Area(L*W) | 60.0x18.5 mm |
| Active Area(L*W) | 56.03x14.53 mm | Character Size(L*W) | |
| Type | COG | Connection Method | FPC |
| Supply Voltage | 3.3V | Interface Type | 4-bit or 8-bit parallel port |
| Viewing Direction | 6 O'CLOCK | Driving Method | 1/32Duty |
| Display Type | Driver IC | ST7567 | |
| Operating Temperature | -20℃~+70℃ | Storage Temperature | -30℃~+80℃ |
| Backlight parameters | 3.3V | production capacity | Self-produced |
| Character libraries | Whether to bring PCB | NO |
